Name: Fieldpiece Dual Voltage 6CFM Vacuum Pump -VP633UK (ATEX Rated)
SKU: VP67
Availability: InStock

Information

Fieldpiece ATEX Rated 6CFM Vacuum Pump dual Voltage 230v/110V

Fieldpiece offers high performance ATEX Rated 6 CFM vacuum pumps that cut evacuation time.

ATEX Rated to work with A3 refrigerants;
RunQuick® Oil Change System to change oil in less than 20 seconds;
Lightweight and portable design of only 13kg & down to 15 microns ultimate vacuum;
4 in-line ports for easy hose connection;
A3 and A2L compatible.

Our 6CFM ATEX-Rated Vacuum Pump has been designed to easily and quickly perform a vacuum on a system.

Four reasons why you need our VP6331. Work safely with our ATEX Rated pumpDo you work with A3 refrigerants? No need to worry! Our VP833 vacuum pump is ATEX Rated, ensuring safe operation in potentially explosive environments. This certification confirms that the VP833 is compatible with A3 refrigerants, allowing you to work confidently.2. Do your job faster with our RunQuick® Oil Change SystemClean oil matters. You–the technician– understand the importance of clean oil, but also the hassle that task usually comes with. With our RunQuick® Oil Change System, we’ve taken away the inconvenience of changing the oil and we have made it possible for you to switch the oil in your vacuum pump in 20 seconds or less without powering down or losing vacuum. And, through the large oil reservoir, you can easily view the condition of your oil in an instant. No mess, quick change, fast vacuum. That’s our VP833.3. Lightweight and portable powerhouseDesigned to handle the demands of any job, the VP833 is light enough to be carried anywhere on site. With a weight of only 13 kg, this Fieldpiece vacuum pump is light but powerful – with the ability to achieve 15 microns ultimate vacuum and is compatible with A3 and A2L refrigerants!

4. Four in-line ports

Four in-line ports to make sure you have plenty of room to easily run multiple hoses. Because of the strategically placed ports, tangled hoses and clutter around your vacuum pump is in the past. Work efficiently with our VP833 and easily connect hoses of ¼”, ⅜”, and ½”.

5. Easy-to-use gas ballast

To engage or disengage the gas ballast valve, simply turn the lever to whatever side is needed. This lever style system ensures that you can easily and quickly change the gas ballast, to make your job easier, better, and faster.

SpecificationsProduct :-

Flow Rate: 6CFM
Ultimate Vacuum at Input Ports: 15 Microns
For Use With: A3, A2L, and A1 Refrigerants
Not for Use With: R-702, R-717
Oil Capacity: 237ml
Oil Compatibility: Fieldpiece Vacuum Pump Oil (Highly refined and optimized for proper sealing and lubrication)Fieldpiece part numbers: OIL8X3, OIL32, OIL128
Oil Backlight: Blue LED
Oil Drain: Ball valve
Port Sizes: (1) 1/4”, (2) 3/8”, (1) 1/2”
Compressor: Rotary vane, two stage
Motor: 1/2 HP AC
RPM: 2866 (VP633 ~ 50 Hz)
Power Source: 110/230 VAC Selectable 50 Hz (VP633)
Nominal Current Draw: 5A @ 110 VAC, 2A @ 230 VAC (VP633)
Nominal Power: 550W @ 110V, 460W @ 230V (VP633)
Unit Ingress Protection Rating: IP20
Dimensions: 201 mm x 296 mm x 406 mm
Weight Empty: 15 kg
Operating Environment: 0°C to 40°C

Included in package :-

VP633 Vacuum Pump
2x 237ml oil
Appropriate plug based on country
